| Construction: | A high quality combination packing of Graphite bonded PTFE yarn with aramid corners. |
| Application: | This packing has good sliding properties and thermal conductivity, making it an excellent packing option for high pressure pumps with sliding velocity. Aramid yarn corners prevent gap extrusion in high pressure & high temperature applications. It is widely used in applications involving abrasive media. |
| Installation: | Installation Detail |
| Available Size: | From 3mm to 45mm . |
| Service Parameters: |
Temp.
|
pH |
Pressure |
Velocity |
�
C |
Range |
Kg/cm2 |
Mtrs/sec |
|
-240
to 260 |
0-12 |
200 |
20 |
| Standard Packing: |
3mm to 5mm
|
6mm to 14mm |
16mm to 19mm |
Above 19mm |
1/2 kg |
1kg |
2kg2 |
5kg |
:
:
